• Dual Protection – Provides both waterproofing and physical termite exclusion in a single membrane
• Proven Performance – Over 20 years of university testing and ICC ESR-3632 compliance
• Durable Construction – 68-mil composite (HDPE + rubberized asphalt) ensures puncture resistance and flexibility
• All-Weather Application – Formulated for low temperatures down to 30°F (-1°C); 30-day UV exposure window
• Non-Chemical Pest Control – Safe alternative to pesticides; supports LEED credits for sustainable construction
• Immediate Backfill – No waiting period required; compatible with dry soil, sand, or drainage gravel when used with Polyflow® 15P
• Easy Installation – Strong, pliable, peel-and-stick sheet with excellent adhesion to primed substrates

• Membrane Thickness: 68 mils (ASTM D 1000)
• Color: Red / White
• Elongation (Barrier Sealant): > 1000% (ASTM D 412)
• Pesticide Repellency: 0% penetration (ASTM F 2130, tested against Chlordane, Fipronil, Permethrin)
• Moisture/Vapor Permeance: 0.03 grains/ft²/hr/in (ASTM E 96 Method B)
• Tensile Strength (Composite): 325 psi (ASTM D 412 Modified Die C)
• Peel Adhesion: 10 lbs/in width (ASTM D 1000)
• Overlap Bond: 8 lbs/in width (ASTM D 1000)

Primary Uses

• Foundation waterproofing with termite exclusion
• Protects building foundations from both water intrusion and termite penetration

Compatible Substrates & Systems

• Concrete foundation walls — intended for standard concrete substrates
• ICF (Insulated Concrete Forms) — common in residential and commercial foundations
• Building envelope systems — integrates into waterproofing and pest-control strategies

Typical Project Types

• Residential foundation waterproofing
• Commercial foundation construction
• Below-grade walls
• Slab-edge termite protection zones
• Projects requiring ICC-recognized termite barrier compliance

Surface & Installation

• Peel-and-stick self-adhesive membrane for simplified installation
• Strong, pliable HDPE composite sheet
• 4-mil HDPE bonded to 64-mil barrier sealant (~68 mil total thickness)

Temperature & Jobsite Conditions

• Can be installed in temperatures down to 30°F (-1°C)
• 30-day UV exposure tolerance before covering

Backfill Guidance

• No waiting period required before backfilling
• Recommended backfill material: dry sand or dry soil
