• Dual Protection – Channels water away from foundations while shielding the primary waterproofing barrier during backfill
• High Compressive Strength – Withstands up to 11,000 psf, ensuring durability under soil and structural loads
• Lightweight & Easy to Install – 38 lbs. per roll allows for quick handling on-site
• Optimized Drainage – Flow capacity of 18 gpm/ft for effective hydrostatic pressure relief
• Economical Solution – Cost-effective waterproofing protection compared to thicker, rigid boards
• System Compatibility – Complements Poly Wall® membranes, Totalflow™ systems, and perforated pipe outlets for high-capacity drainage

Core Properties:

• Material: Polymeric
• Thickness: 0.40 in.
• Compressive Strength: 11,000 psf
• Flow Capacity: 18 gpm/ft

Fabric Properties:

• Material: Polymeric
• Grab Tensile Strength: 100 lbs.
• CBR Puncture Strength: 250 lbs.
• Apparent Opening Size (AOS): 70 US Sieve
• Flow Rate: 140 gpm/ft²

Roll Dimensions:

• Roll Length: 50 ft.
• Roll Width: 4 ft.
• Roll Weight: 38 lbs.

Foundation & Below-Grade Drainage

• Foundation wall drainage systems
• Basement waterproofing assemblies
• Retaining wall drainage
• Below-grade structure protection
• Designed specifically for vertical applications managing subsurface water around foundations

Hydrostatic Pressure Relief Systems

• Drainage behind foundation walls
• Gravity drain or sump-connected systems
• Water management behind waterproof membranes
• Helps relieve hydrostatic pressure buildup to prevent water intrusion and structural stress

Waterproofing Protection Layer

• Protection board over liquid or sheet waterproofing
• Backfill protection for membranes
• Drainage composite within waterproofing systems
• Acts as a barrier to help prevent membrane damage during backfill

Integrated Drainage Systems

• Used with perforated pipe drainage
• Compatible with collector drain systems
• Channels water efficiently to designated drainage exits

Common Uses

• Foundation waterproofing drainage
• Retaining wall water management
• Basement moisture protection
• Protection board for waterproof membranes
• Below-grade hydrostatic pressure relief

Polyflow® 10 is designed for vertical foundation wall applications where it:

• Relieves hydrostatic pressure by channeling groundwater to a sump or drain tile
• Protects below-grade waterproofing membranes from punctures during backfill
• Provides secondary water management when combined with Polyguard drainage accessories

Common Substrates:

• Concrete foundation walls
• Masonry block walls
• Shotcrete walls
• Insulated concrete form (ICF) systems

Installation Notes:

• Install with fabric side facing the soil to filter particles
• Connect to perforated pipe outlets or sump systems for drainage discharge
• Immediately backfill with soil, sand, or gravel once installed
